wiring jzx100 harness without chassis harness

jzx100/jzx110

  • Please log in to reply
6 replies to this topic

#1 Guest_david s12_*

Guest_david s12_*
  • Guests

Posted 09 September 2011 - 03:59 AM

hey guys

take in mind this s12 has no chassis harness. fuel pump/starter everything else is wired away from the engine harness
ive searched the web a decent amount of times but i dont really need a ECU pinout or some supra conversion to answer my problem. all i need is 12 volt fused power to the right wires to keep the car moving down the track sideways.

i finally aquired my jzx100 harness pretty cheap, previously i had a jzx110 motor with a jzx100 maf/ecu and a non vvti throttlebody i think since i got sorta screwed from the importer. i temporarily wired the jzx110 harness into a sorta half ass jzx100 harness but i still was having slight issues with it


so the basics of the wiring i got through, (with this new jzx100 harness)

i added 12 vt fused power to the blue body harness plug with the 11 black/white wires for the injectors and coils etc.

and also 12 vt fused power to +b etc to keep the ecu on



from what i understand theres got to be more on the body side of the plugs (which are now in the car instead of the engine bay!)

like the positive source for the maf is black/red and is connected to the o2 sensor and some other shit. i hooked up the red/blk wire to one of the chassis plugs and now the maf/o2 sensor has 12 volts going through it with the key on.


but is there any other wires off the body plugs that are main functions for all the basic sensors to work? my jzx110 intake mani doesnt have a IACV, i dont have a p steer pump or a/c compressor on the motor either. motor is stock as balls,

just trying to make sure i didnt miss some sort of main function wire off the body plugs that can give power elsewhere



i also found a gray resistor looking thing off the intake manifold thats 1 wire and bolted to the mani in the back. now since i swapped to a oem jzx100 harness i dont seem to have a plug for this, or anything similar to repin too. i havent really looked at a oem jzx100 so i wouldnt know.. ive just mainly worked with this jzx110



test drove the car today at operating temps,

it breaks up constantly after hwta feels around 4k ish. no matter what throttle i give it, 1/4 or WOT is just starts to consistently break up but not randomly, almost feels like its ignition cutting it or something. it will still rev past that but just gets worse

by the way, when i swapped to jzx100 harness the only connecter i had to swap was the coolant temp sensor plug was different, though i still ran the car like this before with the same ecu without breaking up

any help would be apreciated. thanks


this has given me some insight
http://www.supraforu...harness-diagram


edit* wow didnt realize there is a video in that thread, i thought it was a picture. great info actually sorta sums this up other then the issue im having with it breaking up

http://s981.photobuc...nt=IMAG0037.mp4

#2 Kyle

Kyle

    1jz/holset whore

  • real members
  • 4,748 posts
  • Gender:Male
  • Location:heaven
  • Interests:speed parts made by chinese children and jz powered lithium
  • Powered By:Dicks
  • Country:Texas

Posted 09 September 2011 - 06:37 AM

besides power to that blue plug, here's what I got. car runs like a champ. refer to jzx90 pinout for these plugs if you need to, thats what I did.
Posted Image

#3 Kyle

Kyle

    1jz/holset whore

  • real members
  • 4,748 posts
  • Gender:Male
  • Location:heaven
  • Interests:speed parts made by chinese children and jz powered lithium
  • Powered By:Dicks
  • Country:Texas

Posted 09 September 2011 - 07:42 AM

Oh, maybe try all your ignition powers to a separate circuit. Is everything tied into one? I had to nigger rig my alternator signal on the side of the road and put it into the b1 plug which on my car gives power to ignition, injectors, and everything else like o2 and iacv and shit. they each have their own pin in that plug. i ran a wire for the alt into the ignition one and was experiencing break up like you say. sorry for the novel, hope that helps

#4 Guest_david s12_*

Guest_david s12_*
  • Guests

Posted 09 September 2011 - 11:20 PM

my alt wires go straight to the alt main power stud to get the alternator working which was fine with the jzx110 ghetto harness too.

ill try different setups. i just hope the jzx110 motor doesnt have a a different crank or cam angle sensor, honestly before it didnt break up but it had like no top end even when the afr's were fine


on your smaller plug i dont think i even need MREL or that other pin you have there hooked up it will still run without breaking up, though i do have mrel powerd though.

i dont think its the chassis wiring anymore. unless im missing more then red/blk wire for maf/o2 sensor et, the alt wiring, the black/white wires wired and some grounds

i was more worried about this resistor thing i have no plug for now

#5 Guest_david s12_*

Guest_david s12_*
  • Guests

Posted 09 September 2011 - 11:24 PM

and i think your jz is non vvti right?

#6 Guest_david s12_*

Guest_david s12_*
  • Guests

Posted 10 September 2011 - 12:31 AM

heres a update* i was using my jzx110 harness and cross referencing pins on the maf etc. and tried unplugging the o2 sensor.

its too late to drive the car but the cutting out stopped at least at idle rev's. took like two revs but then it went away. is there extra wiring for the o2 sensor? maybe kine is just jacked up from my repinning process

Posted Image

#7 Kyle

Kyle

    1jz/holset whore

  • real members
  • 4,748 posts
  • Gender:Male
  • Location:heaven
  • Interests:speed parts made by chinese children and jz powered lithium
  • Powered By:Dicks
  • Country:Texas

Posted 10 September 2011 - 06:19 AM

my car is vvti.
